APD F112-N200/Y高壓DC/DC轉換器模塊

發(fā)布時間：2025-08-19 09:10:20 瀏覽：958

　　American Power Design, Inc. 的F1 系列微型穩(wěn)壓高壓 DC/DC 轉換器提供 100% 可編程高壓輸出。輸出電壓監(jiān)控器和板載精密基準是標準配置。所有型號都可以無限期地容忍短路。

APD F112-N200/Y高壓DC/DC轉換器模塊

　　型號：

5VDC INPUT MODELS
REPRESENTATIVE MODEL LISTING
MODEL NUMBER		INPUT CURRENT		OUTPUT SPECIFICATIONS
Non-RoHs	RoHs	NO LOAD	FULL LOAD	VOLTAGE	RIPPLE	CURRENT	REGULATION
Non-RoHs	RoHs	NO LOAD	FULL LOAD	VOLTAGE	RIPPLE	CURRENT	LOAD	LINE
F15-P10	F15-P10/Y	<65 mA	<420 mA	0 to+100Vdc	<0.05%(50mV p-p)	0-10mA	<0.05%	<0.01%
F15-N10	F15-N10/Y	<65 mA	<420 mA	0 to-100Vdc	<0.05%(50mV p-p)	0-10mA	<0.05%	<0.01%
F15-P20	F15-P20/Y	<65 mA	<420 mA	0 to +200Vdc	<0.01%(10mVp-p)	0-5mA	<0.01%	<0.01%
F15-N20	F15-N20/Y	<65 mA	<420 mA	0 to -200Vdc	<0.01%(10mVp-p)	0-5mA	<0.005%	<0.003%
F15-P30	F15-P30/Y	<65 mA	<420 mA	0 to+300Vdc	<0.01%(30mV p-p)	0-3.3mA	<0.005%	<0.003%
F15-N30	F15-N30/Y	<65 mA	<420 mA	0 to-300Vdc	<0.01%(30mVp-p)	0-3.3mA	<0.005%	<0.003%
F15-P50	F15-P50/Y	<65 mA	<420 mA	0 to+500Vdc	<0.005%(25mVp-p)	0-2mA	<0.003%	<0.002%
F15-N50	F15-N50/Y	<65 mA	<420 mA	0 to-500Vdc	<0.005%(25mVp-p)	0-2mA	<0.005%	<0.002%
F15-P60	F15-P60/Y	<65 mA	<420 mA	0 to+600Vdc	<0.005%(30mVp-p)	0-1.67mA	<0.005%	<0.002%
F15-N60	F15-N60/Y	<65 mA	<420 mA	0 to-600Vdc	<0.005%(30mVp-p)	0-1.67mA	<0.005%	<0.002%
F15-P100	F15-P100/Y	<65 mA	<420 mA	0 to+1000Vdc	<0.001%(10mVp-p)	0-1mA	<0.005%	<0.001%
F15-N100	F15-N100/Y	<65 mA	<420 mA	0 to-1000Vdc	<0.001%(10mVp-p)	0-1mA	<0.005%	<0.001%
F15-P125	F15-P125/Y	<65 mA	<420 mA	0 to+1250Vdc	<0.001%(12mVp-p)	0-0.8mA	<0.005%	<0.001%
F15-N125	F15-N125/Y	<65 mA	<420 mA	0 to-1250Vdc	<0.001%(12mVp-p)	0-0.8mA	<0.005%	<0.001%
F15-P150	F15-P150/Y	<155 mA	<550 mA	0 to+1500Vdc	<0.001%(15mVp-p)	0-0.67mA	<0.005%	<0.001%
F15-N150	F15-N150/Y	<155 mA	<550 mA	0 to-1500Vdc	<0.001%(15mVp-p)	0-0.67mA	<0.005%	<0.001%
F15-P200	F15-P200/Y	<155 mA	<550 mA	0 to+2000Vdc	<0.001%(20mVp-p)	0-0.5mA	<0.005%	<0.003%
F15-N200	F15-N200/Y	<155 mA	<550 mA	0 to-2000Vdc	<0.001%(20mVp-p)	0-0.5 mA	<0.001%	<0.001%

12VDC INPUT MODELS
REPRESENTATIVE MODEL LISTING
MODEL NUMBER		INPUT CURRENT		OUTPUT SPECIFICATIONS
Non-RoHs	RoHs	NO LOAD	FULL LOAD	VOLTAGE	RIPPLE	CURRENT	REGULATION
Non-RoHs	RoHs	NO LOAD	FULL LOAD	VOLTAGE	RIPPLE	CURRENT	LOAD	LINE
F112-P10	F112-P10/Y	<80 mA	<220 mA	0 to+100Vdc	<0.05%(50mVp-p)	0-10mA	<0.05%	<0.01%
F112-N10	F112-N10/Y	<80 mA	<220 mA	0 to-100Vdc	<0.05%(50mVp-p)	0-10mA	<0.05%	<0.01%
F112-P20	F112-P20/Y	<80 mA	<220 mA	0 to+200Vdc	<0.01%(10mVp-p)	0-5mA	<0.05%	<0.01%
F112-N20	F112-N20/Y	<80 mA	<220 mA	0 to -200Vdc	<0.01%(10mV p-P)	0-5mA	<0.05%	<0.01%
F112-P30	F112-P30/Y	<80 mA	<220 mA	0 to +300Vdc	<0.01%(30mVp-p)	0-3.3mA	<0.05%	<0.01%
F112-N30	F112-N30/Y	<80 mA	<220 mA	0 to-300Vdc	<0.01%(30mVp-p)	0-3.3mA	<0.05%	<0.01%
F112-P50	F112-P50/Y	<80 mA	<220 mA	0 to+500Vdc	<0.01%(50mVp-p)	0-2mA	<0.01%	<0.01%
F112-N50	F112-N50/Y	<80 mA	<220 mA	0 to-500Vdc	<0.01%(50mVp-p)	0-2mA	<0.01%	<0.01%
F112-P60	F112-P60/Y	<80 mA	<220 mA	0 to+600Vdc	<0.01%(60mVp-p)	0-1.67mA	<0.01%	<0.01%
F112-N60	F112-N60/Y	<80 mA	<220 mA	0 to -600Vdc	<0.01%(60mV p-p)	0-1.67mA	<0.01%	<0.01%
F112-P100	F112-P100/Y	<80 mA	<220 mA	0 to+1000Vdc	<0.001%(10mVp-p)	0-1mA	<0.005%	<0.001%
F112-N100	F112-N100/Y	<80 mA	<220 mA	0 to-1000Vdc	<0.001%(10mVp-p)	0-1mA	<0.005%	<0.001%
F112-P125	F112-P125/Y	<80 mA	<220 mA	0 to+1250Vdc	<0.0005%(6mVp-p)	0-0.8mA	<0.005%	<0.001%
F112-N125	F112-N125/Y	<80 mA	<220 mA	0 to-1250Vdc	<0.0005%(6mVp-p)	0-0.8mA	<0.005%	<0.001%
F112-P150	F112-P150/Y	<100 mA	<220 mA	0 to+1500Vdc	<0.001%(15mVp-p)	0-0.67mA	<0.01%	<0.01%
F112-N150	F112-N150/Y	<100 mA	<220 mA	0 to-1500Vdc	<0.001%(15mVp-p)	0-0.67mA	<0.01%	<0.01%
F112-P200	F112-P200/Y	<100 mA	<220 mA	0 to +2000Vdc	<0.001%(20mVp-p)	0-0.5mA	<0.01%	<0.01%
F112-N200	F112-N200/Y	<100 mA	<220 mA	0 to-2000Vdc	<0.001%(20mVp-p)	0-0.5mA	<0.01%	<0.01%

　　電氣規(guī)格

參數	5V輸入型號	12V輸入型號
輸入電壓范圍	4.75-5.25Vdc	11.5-15.5Vdc
滿載輸入電流（典型）	420-550mA	220mA
輸出紋波（峰峰值）	<0.001% (10mV)	<0.001% (10mV)
負載調整率	<0.05%	<0.05%
線性調整率	<0.01%	<0.01%
開關頻率	180-250kHz	同左
